Altronix DPT724A din mount 7day 24 hr event tmr

Overview
Model DPT724A is an extremely versatile 24Hour 365 Day Event Timer designed to support a
wide range of applications.    Features/Specifications
• 12 to 24 volts AC or DC operation.
• Standby current: 10mA (relay off) 50mA (relay on).
• Battery charging current: 100mA.
• Form "œC" relay contacts are rated 10 amp @ 120VAC/28VDC.
• EE Prom memory protects against loss of programming due to power failure.
• Accurate crystal controlled clock.
• Momentary and/or Latching Events.
• 50 individually programmed daily/weekly events.
• Block programming capacity can accommodate a total of
350 events per week.
• 10 programmable Holiday dates.
• "œFirst man in" option.
• Alphanumeric LCD display simplifies programming.
• Standard or Daylight Savings Time settings.
• Automatic compensation for leap year.
• Built-in charger for 12VDC sealed lead acid or gel type batteries.
• Max charge current 100mA.
• Lithium battery backup maintains clock (optional). (Altronix part # LB2032.)
• DIN Rail mount ready.
• Lifetime Warranty.

Board
• Dimensions (approximate): 5.25"W x 3"L x 1"H

Applications
• Home and Building Automation, Security, Access Control, Lighting Control, Etc.
